Evaluation Kits
Evaluation Kits120 MP

The Canon 120MXS Evaluation Kit includes a camera with a Monochrome, Color, or RGB-NIR sensor and a USB 3.1 interface for simple connectivity. Test high resolution capabilities today using Canon's 120 MP CMOS Sensor.

Learn More
Evaluation Kits35MMFHDXS/LI3030

The Canon 35MMFHDXS Evaluation Kit allows integrators and end users to assess sensor performance and provides assets for image system designers to help accelerate development time.

Learn More
Evaluation KitsLI8020

The Canon LI8020 Evaluation Kit is equipped with APS-H 250M pix CMOS sensor and ultra-high resolution imaging with 250 million pixels.

Learn More
Evaluation KitsLI5040

The Canon LI5040 Evaluation Kit ....

Learn More

Order a Canon CMOS Sensor Evaluation Kit

Selecting the right imaging sensor can open up a world of possibilities for your applications. Canon’s Evaluation Kits have what you need to explore.

The included camera with a pre-installed sensor of your choice features an open architecture design and flexibility to test many of the sensor’s features and capabilities. Resources based on the camera design and sensor functionality are also available to help accelerate your development when designing your own imaging system.

Help enhance results for imaging applications you’re working on now, or tackle those for which a solution was not yet possible, by leveraging the unique capabilities of CMOS sensors from Canon.

Canon CMOS Sensor Evaluation Kit includes:

  • Evaluation camera with pre-installed sensor (mono, RGB, or RGB-NIR)
  • Accessory package for out-of-the-box operation (quick start guide, power supply, cables)
  • Embedded software to setup the sensor, acquire image data, and communicate over USB 3.1 interface with any USB 3 compliant UI
  • PC-based UI application available for download to communicate with the camera
  • Sensor board design files source code*
  • VHDL code for the FPGA*

*Source code and VHDL code only available upon request with an NDA

Lens is not included

Technical Specifications

Evaluation Kit Camera Specs
FPGA Intel Arria 10
FPGA Processor Dual Core A9 ARM
Interface USB 3.1 Gen 1
Programmable General Purpose I/O 4 External FPGA GPIO Pins
Bit Rate 8-Bit
ISP Functions Region of Interest
Exposure Control
Framerate Control
Bad Pixel Replacement
Trigger Mode External
Debug / Registry  Setting Control Peek / Poke Commands
Power Input 12 VDC

Lens Selection

As the lens plays a critical role in any imaging system, it is imperative that a suitable lens be selected to properly evaluate sensor performance for your end application.

When selecting an appropriate lens, there are several key factors which must be considered: Lens Type, Lens Mount, Focal Length, Sensor Size, Resolving Power, and Aperture, to name a few of the more important ones. Some of these factors are associated with your application, and some are directly tied to how the CMOS sensor will perform.

For more about lens selection, please refer to the information on the specific Evaluation Kits pages or request to speak with a Canon Sensor specialist.

Order Canon CMOS Sensor Evaluation Kits Today

Discover new possibilities in industrial vision with Canon CMOS Sensors.
Click below to learn more.
